Durable 0.6/1kV Aluminum PVC Insulated Cables for Reliable Low-Voltage Power Distribution
Product Introduction
Our comprehensive range of single-core aluminum PVC Insulated Cables is engineered for reliable fixed electrical installations in low-voltage power distribution networks and industrial equipment. Designed for a rated voltage of 0.6/1kV, these cables feature aluminum conductors (Class 1 solid or Class 2 stranded as per IEC 60228) and are insulated with high-quality PVC, rated for a maximum continuous conductor temperature of 75°C. Available in a wide cross-sectional range from 1.0 mm² to 400 mm², these versatile PVC Insulated Cables are perfectly suited for both indoor and outdoor applications where they are protected from direct mechanical stress, providing a cost-effective and dependable wiring solution for markets including the EU, North America, and Southeast Asia.
Features & Benefits
-
Cost-Effective & Reliable: Utilizing aluminum conductors, these PVC Insulated Cables offer an excellent balance of performance and economy for a wide array of electrical distribution tasks, from building wiring to supplying power to industrial machinery like lipstick filling machines.
-
Durable & Safe Construction: The PVC insulation and sheath provide robust resistance to environmental factors, abrasion, and moisture. Available options include flame-retardant (FR-PVC) sheath for enhanced fire safety, making these cables a secure choice for various installations.
-
Global Standards Compliance: Manufactured to meet IEC, BS, UL, and GB standards, and backed by certifications like CE, KEMA, and CCC, our cables ensure international acceptance and reliable performance, which is crucial for projects in regulated markets.
-
Easy Installation & Flexibility: The cable design allows for straightforward laying in conduits, ducts, or cable trays. With clear specifications for minimum bending radius, these PVC Insulated Cables simplify on-site installation, saving time and labor costs.
Why Choose Our PVC Insulated Cables?
Shanghai Shenghua Cable (Group) is committed to delivering quality and value. We combine rigorous manufacturing processes with extensive industry experience to produce PVC Insulated Cables that you can trust. Our commitment extends beyond the product, including comprehensive pre-sales support, customizable packaging (on reels or in coils), and reliable on-time delivery to prevent project delays. We stand behind our products with a solid 12-month warranty backed by PICC, ensuring peace of mind for our clients in Vietnam, Southeast Asia, and beyond. Our dedicated 24/7 service hotline underscores our promise to resolve any query promptly.
Technical Data Overview
|
Conductor Cross-Section
|
Insulation Thickness
|
Approx. Cable Diameter
|
Max. DC Resistance at 20°C
|
|
1.5 mm²
|
0.8 mm
|
6.1 mm
|
12.1 Ω/km
|
|
4 mm²
|
1.0 mm
|
7.4 mm
|
4.61 Ω/km
|
|
10 mm²
|
1.0 mm
|
9.2 mm
|
3.02 Ω/km
|
|
25 mm²
|
1.2 mm
|
12.0 mm
|
1.20 Ω/km
|
|
95 mm²
|
1.6 mm
|
19.3 mm
|
0.320 Ω/km
|
(Partial table. Full range from 1.0mm² to 400mm² available.)
Key Specifications: Rated Voltage: 0.6/1 kV | Max. Conductor Temp: 75°C | Test Voltage: 3.5 kV AC for 5 min | Min. Bending Radius: 20 x O.D. (Single Core)
FAQ
Q: What are the primary applications for these Aluminum PVC Insulated Cables?
A: These cables are designed for fixed electrical wiring in power distribution networks, industrial control panels, and building services. They are ideal for indoor use, in cable trenches, or conduits where they are protected from significant mechanical damage, perfectly serving facilities from factories to commercial buildings.
Q: Are these cables suitable for outdoor use in climates like Southeast Asia?
A: Yes. The PVC insulation and sheath provide good resistance to moisture, sunlight (UV stabilized options available), and a range of temperatures, making these PVC Insulated Cables suitable for outdoor use in regions like Vietnam and Southeast Asia, provided they are installed in appropriate conduits or trunking for full protection.
Q: What certifications do you hold for international export, such as to the EU?
A: Our cables are manufactured to key international standards (IEC, BS) and carry CE marking, which is essential for the European market. We also hold KEMA, CCC, and other certifications, and can provide test reports upon request to facilitate customs clearance and project approval.
Q: What is your packaging and delivery process for overseas orders?
A: We pack cables securely on wooden reels or in coils, with ends sealed against moisture. Orders are shipped in standard containers, and we work closely with logistics partners to ensure on-time delivery, which is a top priority for us to support your project schedule anywhere in the world.
